型號

TYPE

PSG630P-R-RP

PSG1000P-R-RP

PSG1300P-R-RP

加工寬度

Working Width

30--630mm

30--1000mm

30--1300

加工厚度

Working Thickness

2--100mm

2-100mm

2-100mm

加工長度

Working Length

≥420mm

≥420mm

≥510mm

送料速度

Feed Speed

5-25m/min

5-25m/min

5-25m/min

電機總功率

Total Motor Power

36.25KW

48.05KW

78.55KW

止逆裝置

Anti Rebound Device

有

有

有

彈力壓靴

Press Shoe

有

有

有

工作氣壓

Working Air Pressure

≥0.6Mpa

≥0.6Mpa

≥0.6Mpa

工作電壓

Working Voltage

380V 50HZ

380V 50HZ

380V 50HZ

吸塵風速

Speed Of Suckeed Air

8200m3/h

8200m3/h

8200m3/h

吸塵口直徑

Vacuuning Mouth Diameter

?150*3個

?150*3個

?200*3個
